ER 20


The ER 20 is a four axle diesel-electric locomotive from Siemens for the passenger and freight market.

Quickinfo

ManufacturerSiemens/MTU
Build since2002
SuppliesDiesel-Electric
Power2,000 kW
Countries/HomologationsDE/AT/CZ
Safety SystemsPZB

Technical details ER 20

Data general
ManufacturerSiemens/MTU
Build since2002
Countries/HomologationsDE/AT/CZ
Dimensions
Track gauge1,435 mm
Wheelset arrangementBo’Bo’
Wheel diameter1,100 mm
Length over buffer19,275 mm
Total height4,180 mm
Total width2,980 mm
Weight
Total weight80 tons
Wheelset load20 tons
Traction, Engine & Power
ManufacturerMTU
SuppliesDiesel-Electric
Power2,000 kW
Tank capacity2,800 L
Speed, Traction performance & Additionals
Maximum speed140 km/h
Starting tractive effort235 kN
Minimum curve radius100 m
Safety SystemsPZB

Countries/Homologations

Countries/Homologations ER 20
DE/AT/CZ
